Features Highlight:
• High-Brightness LCD Panel
• All Weather Proof IP65 Enclosures
• Operating Temperature -40C To 50C*
• Integrated heater and air conditioner
• Slim Bezel Thickness 18mm only
• Vandal Resistant Screen & housing
• Unique Front Access Design
• Remote Reboot/Temp.& Humidity Monitoring available (Optional)
• Wireless and VGA/DVI CAT5 signal extenders available (Optional)
Technical Specifications:
Active area size (W x H): 46” (1018.353 x 572.544 mm)
Pixel pitch (mm): 0.2485(H) x 0.7455(V)
Panel resolution (pixels): 1366 x 768
Luminance of white (Brightness): 1500 nits (Typ)
Contrast ratio: 3000:1
Response time (gtg): 8 ms (Typ)
Colour Range: 16.7 Million colours (max)
Viewing angle: 89/89/89/89
Video inputs: VGA; HDMI; S-Video
Auto Brightness Control: Yes (Optional)
Front glass type: strengthen 6mm AR glass
IP Class: IP65
Operating temperature range: -40 to + 95F (Direct Sunlight) /122F (Under Shaded Area)
Storage Temperature: 0 to 50C
CCFL Life: Time 60K hrs (min)
Input voltage: 110V
Weight: 70kg/195lbs
External dimensions (W x H x D): 1056 x 610 x 249 mm Notes: to guarantee a proper functionality, 10cm of clearance must be kept around the display (41.6” W x 24” H x 9.81”D)
Portrait version: Please contact SuntronicLCD for details
Available Accessories: IR Remote Control
VGA cable (included) and Ethernet Cable (not included)
Options: Custom Embedded PCs (please call for enquiries)
Customization: Please contact SuntronicLCD for available options |
